EDWARDS 75 TON HYDRAULIC IRONWORKER BRAND NEW HEAVY DUTY USA MADE 1 YEAR WARRANTY 10
Ironworkers
.jpg)
.jpg)
| Tonnage | 75 T |
| Angle (L1) | 5" |
| Angle (L2) | 5" |
| Angle (T) | 0.5" |
| Power | 7.5 hp |
| Throat | 10" |
| Stroke | 1.8125" |
| Dimensions | 5 X 5 X 4' |
| Weight | 4000 LBS |
SPECIFICATIONS
Tonnage: 75
Max Capacity: 1-1/16" Dia. in 7/8" A36
(65,000 PSI Tensile)
Stroke: 1-13/16"
Throat Depth: 10"
Open Height: 8-3/4"
Shut Height: 6-15/16"
Work Height: 39-1/16"
Standard Motor: 7.5 HP 3~ 208 V or 230 V
1765 RPM 22 A
Four Available Workstations
Punch Assembly Designed for Optional Tooling
Dedicated Coper Notcher Station
Electric Stroke Control
ANSI B11.5-1988R(02) Compliant
ETL/UL Approved Controls
DIMENSIONS -
Height: 60-1/4"
Width: 50"
Depth: 45"
Weight: 4100 LBS
Full Specs Available Upon Request
***1 Year Warranty through Edwards***
The optional PowerLink System allows your Ironworker to act as a power source to our expanding line of innovative PowerLink Hydraulic Tools, such as the 10 Ton Tube/Pipe Bender, 20 Ton Shop Press and 40 Ton Shop Press.
Due to eBay's policy we do not have our contact information listed. The only way we can communicate with you
PUNCH
ANGLE SHEAR
COPER NOTCHER
FLAT BAR SHEAR
OPTIONS,
PRESS BRAKE
ROD SHEAR
POWER LINK HYDRAULICS
HEX, SQUARE AND OBLONG PUNCHES AND DIES
PRODUCTIVITY PACKAGES
| Tonnage | 75 T |
| Angle (L1) | 5" |
| Angle (L2) | 5" |
| Angle (T) | 0.5" |
| Power | 7.5 hp |
| Throat | 10" |
| Stroke | 1.8125" |
| Dimensions | 5 X 5 X 4' |
| Weight | 4000 LBS |
SPECIFICATIONS
Tonnage: 75
Max Capacity: 1-1/16" Dia. in 7/8" A36
(65,000 PSI Tensile)
Stroke: 1-13/16"
Throat Depth: 10"
Open Height: 8-3/4"
Shut Height: 6-15/16"
Work Height: 39-1/16"
Standard Motor: 7.5 HP 3~ 208 V or 230 V
1765 RPM 22 A
Four Available Workstations
Punch Assembly Designed for Optional Tooling
Dedicated Coper Notcher Station
Electric Stroke Control
ANSI B11.5-1988R(02) Compliant
ETL/UL Approved Controls
DIMENSIONS -
Height: 60-1/4"
Width: 50"
Depth: 45"
Weight: 4100 LBS
Full Specs Available Upon Request
***1 Year Warranty through Edwards***
The optional PowerLink System allows your Ironworker to act as a power source to our expanding line of innovative PowerLink Hydraulic Tools, such as the 10 Ton Tube/Pipe Bender, 20 Ton Shop Press and 40 Ton Shop Press.
Due to eBay's policy we do not have our contact information listed. The only way we can communicate with you
PUNCH
ANGLE SHEAR
COPER NOTCHER
FLAT BAR SHEAR
OPTIONS,
PRESS BRAKE
ROD SHEAR
POWER LINK HYDRAULICS
HEX, SQUARE AND OBLONG PUNCHES AND DIES
PRODUCTIVITY PACKAGES
| $27,199.00 USD |
