SENFENG FIBER LASER 12 KW 6.5' ' X 13' SENGFEN IN STOCK FOR IMMEDIATE DELIVERY INCLUDES SET UP, INSTALLATION , TRAINING
Have one to sell?
$298,000.00 USD
Or as low as $5,960.00 USD/month over 60 months
ConditionNew
1 available
New
Or as low as $5,960.00 USD/month over 60 months
SENFENG 4020H 12KW OR 30 KW OPTION ARE efficient and precise metal cutting machines that can cut both sheets with high stability and reliability. And THEY adopt high-quality mechanical structures and electrical components to operate stably for a long time and reduce failure rate. They can be widely used in metal processing, machinery manufacturing, automobile manufacturing, aerospace and other fields.
With an integrated design, it can cut both sheets and tubes to save purchase costs for users. It also has multifunctionality and high efficiency and can meet the cutting needs of different materials, improving production efficiency.
While ensuring efficient machine operation, the dual auto-exchange worktable achieves safe production and can simultaneously realize loading and unloading and continuous cutting, thereby greatly reducing standby time and improving work efficiency.
Fully enclosed sheet metal protection is a necessary safety measure for laser cutting machines, which can ensure the safety of operators, reduce environmental pollution, and improve production efficiency and equipment reliability.
➤Suitable for sheets and tubes cutting
➤Versatility and efficiency
➤High standard chuck
➤Fast exchange worktable
➤Passed CE, ROHS,FDA, meeting European and American standards
Technical Parameters
Main Parameters
Model
3015H 4020H 6020H 6025H 8025H 12025H
Laser Power (kW) 6-30 6-30 6-30 6-30 6-30 6-30
Working Area (L*W, mm) 3080*1530 4050*2030 6050*2030 6050*2530 8050*2530 12050*2530 1
X/Y-axis Positioning Accuracy (mm) ±0.05 ±0.05 ±0.05 ±0.05 ±0.05 ±0.05 ±0.05
X/Y-axis Repositioning Accuracy (mm) ±0.02 ±0.02 ±0.02 ±0.02 ±0.02 ±0.02 ±0.02
Max No-load Speed (m/min) 180 180 180 180 180 169 180
Max Load of Platforms (kg) 3000 3200 4750 6000 8000 14000 16000
Overall Dimensions (L*W*H, mm) 8440*2270*2340 10876*3363*2515 14887*3363*2515 14740*3893*2515 19075*3893*2515 27927*3893*2515 28877*4233*2515
Performance Benefits
This machine works stably and has good dynamic performance, so as to serve users for a long time at ultra-high power.
1. Cut medium-thick plate
6-90mm stainless steel, 5-80mm carbon steel, 5-60mm AL alloy, 5-30mm brass
2. Multiply cutting speed
About 3-5 times faster than other plate laser cutters
3. High degree of intelligence
Top configurations in both software and hardware, in particular some unique functions, so its oversea market reception is rising steadily
Mechanical Benefits
1. Tried-and-tested design
Double exchange platforms available to save waiting time for loading & unloading
Adopt hollow machine tool and graphite plates as fire prevention
Aviation-grade AL beam at high strength, enabling its cutting into various shapes at high speed
Fully-enclosed structure, with flip-in air door and dust curtain for safety and environmental protection
2. Efficient drive system
We use integrated electronic components & precision guide rail and racks (100% match) to enable high acceleration (2.8G) and positioning accuracy (±0.05mm).
3. High-standard machine tool
Keep machine tool indeformable and unbroken at high temperature even after long-time use because of going through 7 standard processes like 600° high annealing
Control System Benefits
This professional CNC system is internally installed with many functions to easily cut plates at different thicknesses in different work conditions.
1. Lightning-fast piercing
Fast to pierce through thick plates at high quality
2. Visual detection of residues
Further use of residues to minimize plate waste
3. Visual collision avoidance
All-round monitoring without dead zone, making cutting safer
