2026 BODOR P4 60KW, 6' X 13' FIBER LASER, SAVE $$$
Have one to sell?
ConditionNew
1 available
New
Working Envelope
Cutting Area: 4000 × 2000 mm (13.12′ × 6.56′)
Z‑Axis Travel: 315–370 mm (varies by configuration)
Max Table Load: Rated for up to 60 kW cutting applications
Laser Power Options (P4 Series)
6 / 12 / 24 / 30 / 60 kW supported
Your model: 60 kW Maxphotonics (Bodor‑branded)
Performance
Max Acceleration: 4G
Max Linkage Speed: 200 m/min
Positioning Accuracy: ±0.05 mm/m
Repositioning Accuracy: ±0.03 mm
Machine Dimensions
Overall Size: 11599 × 3380 × 2718 mm (from Bodor P4 spec sheet)
🔩 Core Components
Laser Source
Bodor Maxphotonics 60 kW fiber laser
Optimized for thick carbon steel, stainless, aluminum, copper, and high‑reflective materials
Laser Head
Precitec (Germany)
Auto‑focus
High‑pressure cutting
Intelligent anti‑shake
Bodor lightning perforation
Machine Structure
Tenon & mortise bed (high rigidity)
Stretched aluminum gantry
Bodor linear rails + Bodor rack
Control System
Bodor Thinker®
21.5″ touchscreen
WIFI connectivity
Ergonomic Bodor Mango® remote
🧠 Intelligent Features
One‑click processing
Automatic nozzle changer
One‑second edge search
Automatic nozzle cleaning
Intelligent gas pressure control (O₂ / N₂ / Air)
Laser cutting expert database
Active anti‑collision + visual collision detection
Intelligent remnant typesetting
Over‑heat adaptation
Gas‑saving steady‑flow nozzle
🧹 Dust, Air & Cooling Systems
Dust Collector: Included (Laser fume filter)
37 kW Air Compressor: Included
Water Chiller: Included
Transformer: Included
Enhanced‑partition dust removal
🔌 Power Requirements
220V / 440V / 480V, 60 Hz, 3‑phase
Whole‑machine power draw varies by laser power; dealer listing shows ~60 kW average at 12 kW, higher at 60 kW.
📦 Included With Purchase
Freight & tariff: Included
Installation & training: Included
Spare laser head: Included
Consumables package: Included
🛡 Warranty
5 years — laser head
5 years — laser source
5 years — control system
3 years — entire machine (excluding consumables)
📊 Cutting Capability (60 kW)
(From Bodor P‑Series cutting tables — reference only)
Carbon steel: up to ~120 mm
Stainless steel: up to ~80 mm
Aluminum: up to ~60 mm
Copper/brass: up to ~50 mm
📦 Included With Purchase
Freight & tariff: Included
Installation & training: Included
Spare laser head: Included
Consumables package: Included
🛡 Warranty
5 years — laser head
5 years — laser source
5 years — control system
3 years — entire machine (excluding consumables)
📊 Cutting Capability (60 kW)
(From Bodor P‑Series cutting tables — reference only)
Carbon steel: up to ~120 mm
Stainless steel: up to ~80 mm
Aluminum: up to ~60 mm
Copper/brass: up to ~50 mm
